AL1 “Barletta” Area & Path Light

ClaroLux’s Patented AL1 “Barletta” Area Lights offer a uniform light output and feature an easy to remove, screw on top for quick lamp replacement. The fixture provides sufficient light to cast soft glows on any path or walking area. These luminaires are ideal for walkways and planter beds. The AL1 “Barletta” is offered in polished copper, antique brass, and more. Available with direct replacement LEDs in a variety of color temperature and lumen options.

Patent No. US D698,965

Are you just needing a Replacement Top? Shop Light Fixture Tops here >

Buy 50+ Save 3%
Buy 100+ Save 5%
Buy 250+ Save 7%
Buy 500+ Save 10%
(*discount will be applied in cart)

Bulbs

Select a Pole (REQUIRED)

  • Standard 16" Pole *

  • Upgrade to 12"-24" Adjustable Riser Pole *

Custom Color Finish

  • You have selected a Custom Color finish that requires a $25 setup fee. By selecting this you understand and accept this setup fee.

Product total

Options total

Flat rate total

Grand total

Weight 3.5 lbs
Dimensions 8 × 8 × 19 in

Applications

  • Illuminating walkways and flower beds
  • Patios, Driveways, other paved areas
  • Uniform light output without glare

Features

  • Components Precision CNC Machined from C360 Brass Bar Stock
  • Borosilicate Glass Tube
  • Easy to Remove Screw on Top
  • Pre-Greased Copper Beryllium Socket
  • Stainless Steel Screws
  • Slotted ABS Plastic Ground Stake
  • 100% Field Serviceable Design
  • Structural Lifetime Warranty (Copper and Brass)

US Patent No. D698,965

Specifications

  • Bi-Pin
  • Max Wattage: 20W
  • Wire AWG: 18-2
  • Wire Lead: 25ft
  • UL Listed: USA & Canada
  • Lifetime Structural Warranty

> Download Specification Sheet | PDF

Installation Instructions

For use with Low Voltage Landscape Lighting Power units. FOR OUTDOOR USE ONLY.

  • Amps not to exceed: 25 AMPS
  • Volts not to exceed: 12 Volts
  • Max lamp wattage UL 20W & cUL 20W
  • If using halogen, do not exceed 12V at the luminaire
  • If using LED, optimal operating range is 10V-14

WARNING: Luminaire must be installed in accordance with National Electric Code (NEC) and Local Codes. Failure to do so will void all warranties and may result in serious injury and/or damage to the luminaire.

> Download Install Instructions | PDF
